yuandai Electric Bicycle Scooter e-Bike Brushless DC Motor Controller 48V 60V 64V 1500W 45A

Rated Voltage: 48-64V Low Voltage : 41V/52V±0.5V Rated Power: 1500W Limit Current: 45A 48V-64V 1500W controller function 1. instrumentation line （There are two instrument wires, one is suitable for pointer type instrument (green wire), and the other is suitable for liquid crystal type instrument (purple wire), choose wiring according to different instruments） 2. motor line 3. battery line 4. electric lock line 5. hall line 6.self-learning line 7. low brake 8. high brake line 9. 3-speed line 10.reverse line 11.throttle line 12. Cruise speed line 13. Anti-theft power line 14. Anti-theft alarm line 一.connect the motor line (color to color) 二. connect the battery line(red:+ , black:-) 三. connect the controller throttle line, electric lock(electric lock must connect，can connect to key lock, not have key lock，connect to battery +） 四. connect the hall line 五.docking the two self-learning lines, the wheel will forward or reverse. (1.if wheel forward ,Separate the self-learning line. 2.if wheel reverse, Separate the self-learning line. Docking the self-learning line again，if wheel forward ,Separate the self-learning line.) 六.other functions can be connected as needed.
