uxcell DC Push Pull Type Solenoid Electromagnet, DC24V 4.8W 40g 10mm, Open Frame Type, Linear Motion

Description: - Push Pull Type, linear motion, open frame, plunger spring return, DC solenoid electromagnet. - Support DC 24V voltage, linear motion, is easy to install. - DC solenoid electromagnet mainly used in vending machines, transport equipment, office facility, household appliance, mechanical, etc. Specification: - Voltage & Current : DC24V 0.2A - Power : 4.8W - Action Type: Push Pull - Stroke & Force : 10mm, 40g - Wire Length: 21cm / 8.27inch - Plunger Bar Dia: 8mm / 0.31inch - Body Size : 37mm x 45mm x 27mm / 1.46inch x 1.77inch x 1.06inch (L*W*H) - Mounting Hole Size: 7mm x 5mm / 0.28inch x 0.2inch (L*W) - Mounting Hole Distance: 35m x 20mm / 1.38inch x 0.79inch (L*W) - Package Content : 1 x DC Push Pull Type Solenoid Electromagnet Note: - Please pay attention:As an actuating element of an automation equipment ,because the current is large, the single cycle can not be electrified for a long time.The best operate time is in 2 seconds.If the operate time is too long,the electromagnet temperature will rise.Too high temperature can affect the life of the electromagnet. - Please take the electromagnet put down gently when you install it. This product is small in size, please pay attention to in the process of using electricity.
