uxcell 330 Ohm Resistor Network Array, 1/8W SIP-9 2.54mm Pitch, 5% Tolerance Bussed Type 20pcs

Model No.: A331J Resistance: 330 Ohm Tolerance: ±5% (J) Rated Power: 1/8W Max. Working Voltage: 200V Network Type: Bussed Package Type: SIP (Single In-line Package) Pin Quantity: 9 Pin Pitch: 2.54mm Size: 22 x 8.5 x 2mm (0.87" x 0.33" x 0.08") Package Content: 20 x Resistor Network Feature: -Thick film resistor array is a combination of several resistors. -One end of all resistors share a common connection. -Resistor network offers an alternative with multiple potential benefits to both circuit-design and board-layout challenges. -The bussed arrangement is commonly used for pull up, pull down or bus termination on logic signals.
