uxcell 220uF 25V 6x12mm Electrolytic Capacitor, Radial Leads Aluminum Capacitors for TV, LCD Monitor, VCD, 15Pcs

Specification: Capacitance: 220uF Rated Voltage: 25V Capacitance Tolerance: +/-20% (at 120Hz, 20℃) Lead Type: Radial Category Temperature Range: -40℃ to +105℃ (6.3~100V) Life Span: 2000-3000h Body Size: 6x12mm Lead Length: 18mm,23mm Lead Space: 2.5mm Lead Diameter: 0.6mm Package Content: 15 x Electrolytic Capacitors About Item: -Aluminum electrolytic capacitors are designed for use in all types of electronic equipment including power and energy, industrial, telecommunications and consumer electronics applications. -These capacitors offer very long life in applications, with rated temperatures up to 105℃ for general-purpose applications. -Aluminum electrolytic capacitors are used when a large capacitance is required and leakage current is not an important factor. -For use in power supplies and computer motherboards. Pay attention to the following cautions: DO NOT move the capacitor after soldering to PC board. DO NOT pick up the PC board by holding the soldered capacitor. DO NOT insert the capacitor on the PC board with a hole space different from the specified lead space. Take the position of the safety vent into consideration when designing the PC board layout. Excessive soldering time, temperature excessive or mounting force can negatively affect the capacitor's characteristics. The long lead is the positive end, and the shorter one is the negative end. How to select the proper capacitor for your design? Step 1: Determine the capacitance required by the design. Step 2: Define the expected ambient operating temperature. Step 3: Define the DC operating voltage to be applied to the capacitor. Step 4: Bound the space available for the capacitor (if available space is a concern).
