YELUFT 2pcs Nano V3.0 Board ATmega328P MCU CH340G Chip 5V 16M Microcontroller Type-C Port with USB Cable + Nano V3.0 Expansion Board Nano IO Shield V1.O Terminal Adapter Compatible with Arduino IDE

Features

• Main Chip: Nano V3.0 board uses ATmega328P-AU as main chip. Support ISP download, USB download and power supply. Fully compatible with Arduino Nano, Windows, MAC and Linux operating systems
• Upgrade USB Bus Adapter Chip: Upgrade CH340G chip, not FT232, please install the driver first. CH340G supports full-speed USB device interface, compatible with USB V2.0, achieve USB to serial or USB to print port implementation
• Power Supply: Nano board can be powered via Type-C connection, 7-12V unregulated external power supply (pin 30), or 5V regulated external power supply (pin 27). The power source is automatically selected to the highest voltage source, without the need for a power selection jumper
• Perfect Design: Nano V3.0 is a smallest, complete and breadboard friendly board. The board has 14 digital I/O pins, 6 PWM outputs, 8 analog inputs. It is enough for most applications
• Additional Expansion Board: Nano IO Shield V1.O is a terminal expansion adapter board, working very well for prototyping Arduino Nano projects. You can use this Nano V3.0 expansion board to easily hook up Arduino Nano to an outside world via hook up wires, and It can be used in conjunction with or in place of a breadboard
