XIITIA 2pcs 1.69" HD IPS TFT LCD Display Module 240x280 RGB LCD Screen 3.3V ST7789 Drive SPI Interface 8pin Full Color for Arduino DIY

Photo 1 of XIITIA 2pcs 1.69" HD IPS TFT LCD Display Module 240x280 RGB LCD Screen 3.3V ST7789 Drive SPI Interface 8pin Full Color for Arduino DIY
1/2
Photo 1 of XIITIA 2pcs 1.69" HD IPS TFT LCD Display Module 240x280 RGB LCD Screen 3.3V ST7789 Drive SPI Interface 8pin Full Color for Arduino DIY
2/2

Time Left

16 hours

CURRENT PRICE

-

LOGIN TO BID

Description

Features: Size: 1.69-inch IPS color LCD Resolution: 240(H)RGB x280(V) Interface Type: SPI Interface Control Chip: ST7789V2 Highlights: HD IPS, display direction can be adjusted. Display Color: Color Display Area: 27.972(H) x 32.634(V) PCBA Size: 31.00(H) x 48.00(V) x 2.76 (D) Pixel Pitch: 0.11655(H) x 0.11655(V) Number of Pins: 8pin Viewing Angle: Full Viewing Angle Operating Temperature: -20~70 degrees Celsius Logic Voltage: 3.3V Backlight Type: 3 White LED Parallel Brightness: 480 (TYP)Cd/m2 Weight: 8g Connection: 2.54mm pitch single row of pins Pin Description： GND: Power ground VCC: Power Positive 3.3V SCL: SPI clock line SDA: SPI data line RES: LCD reset DC: LCD data/command select pin CS: LCD display chip select signal, active low BLK: Backlight control switch, backlight on by default, low level off the backlight

Item Details

Pickup Location

4000 Meadows Ln

Las Vegas, NV, 89107

Quality

Used
Functional
No Damage
No Assembly Needed
In Package
No Missing Parts

Auction closes

August 26, 2025 at 1:47 AM

brand

XIITIA

Estimated Retail Price

$13.71

Buyers Premium

15%

Inventory Number

1046317355

Found in

Home Improvement

Features

  • ★Size: 1.69-inch IPS color LCD; Resolution: 240(H)RGB x280(V); Interface Type: SPI Interface; Control Chip: ST7789V2
  • ★Highlights: HD IPS, display direction can be adjusted; Display Color: Color; Display Area: 27.972(H) x 32.634(V); PCBA Size: 31.00(H) x 48.00(V) x 2.76 (D); Pixel Pitch: 0.11655(H) x 0.11655(V)
  • ★Number of Pins: 8pin; Viewing Angle: Full Viewing Angle; Operating Temperature: -20~70 degrees Celsius; Connection: 2.54mm pitch single row of pins
  • ★Logic Voltage: 3.3V; Backlight Type: 3 White LED Parallel; Brightness: 480 (TYP)Cd/m2; Weight: 8g
  • ★Pin Description: GND: Power ground; VCC: Power Positive 3.3V; SCL: SPI clock line; SDA: SPI data line; RES: LCD reset; DC: LCD data/command select pin; CS: LCD display chip select signal, active low; BLK: Backlight control switch, backlight on by default, low level off the backlight
