Wengart Blank Face GFCI,Weather Resistant Receptacle Indoor or Outdoor Use,Self-Test with LED Indicator,120V 20Amp,UL Listed, Back &Side Wire,White
Wengart Blank Face GFCI,Weather Resistant Receptacle Indoor or Outdoor Use,Self-Test with LED Indicator,120V 20Amp,UL Listed, Back &Side Wire,White
Description
GFCI is a high-sensitivity, fast-response leakage protection device, which can quickly cut off the circuit and isolate the fault point when a dangerous ground fault leakage occurs, so as to avoid the occurrence of electrical accidents and ensure personal safety. The working principle of GFCI is that when there is equipment leakage or human body gets an electric shock, part of the current flows into the ground, and when the current flowing through the live wire and the neutral wire is not equal (the normal situation is equal), the GFCI monitors the current difference between the live wire and the neutral wire. Once the difference is greater than 6mA, the power supply can be cut off at the moment of 0.025 seconds, so as to ensure the safety of people and property. Widely used in homes, offices, hospitals, schools, hotels, factories and other outdoor venues. Specification: Grounding: Standard Grounding Rated Voltage: 120V Rated Current: 20Amp Application: Residential/General-Purpose Electrical Characteristics: AC120V/20Amp Color:White Unloaded plug≥5000Sec Loop detection with automatic monitoring function Meet the standard:UL,CUL Housing material flame retardant grades Tripping threshold:5mA Tripping time<25ms Surge current:6000V/3000A 6000V/10KA Electric strength:Pressure resistance1500V 50Hz Duration 1Min Insulation resistance:>50MΩ(DC500V) Short-circuit current:10KA Insert and Draw Frequency>10000 times Temperature,humidity:-35℃ ~ +66℃; 20% ~ 90% Storage Temperature,Humidity: -20℃ ~ +85℃; 10% ~ 95%RH
Item Details
Pickup Location
7440 Dean Martin Dr Suite 204
Las Vegas, NV, 89139
Quality
Estimated Retail Price
$11.53
Buyers Premium
15%
Inventory Number
1062969576
Found in
Additional Details from the Manufacturer
This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing
brand
WENGARTcolor
WhiteMore features
- This white face GFCI complies with the latest UL943 Class A standard and provides continuous ground fault protection - it detects actual ground faults and trips even when self-testing.keep your family safe
- This GFCI outlet can provide excellent corrosion resistance, temperature resistance and UV resistance, prevent discoloration and aging, ideal for outdoor and indoor use, very suitable for wet environments, such as bathrooms, balconies, kitchens
- GFCI rated current up to 20Amp, ideal for residential, educational, commercial and industrial use
- GFCI has two buttons, TEST and RESET. TEST button: test whether the GFCI function is working properly before use. It is recommended to test once a month. RESET button: When the outlet triggers the leakage protection, the RESET button pops up and the outlet will be turned off. Pressing RESET will re-energize the outlet. Green light on: RESET button pressed / it tripped (normal operation). Light off: no power supply/wrong wiring (check LINE and LOAD wiring)/failure (replace with new ones).
- Dual indicator lights provide simple and intuitive feedback on power and protection status. If the indicator light (LED) is green, your GFCI receptacle is properly installed and working. When the GFCI outlet reaches the end of its service life, the red indicator light will light up, reminding you to replace the outlet in time.
- This white-faced GFCI features back and side wiring for easy installation without professional help
