WAOUKS 84V 10A Li-ion Battery Charger with Output 3Pin C13 Connector Used for 20S 72V Lithium Battery Charger Cooling Fan Black Aluminum Case

⛳⛳⛳Specification: Product Name: 84V 10A Li-ion Battery Charger Model: WA900-8410B Dimensions: 210x120x70mm Product Weight: 2.2 kg Color/Material: Black/Aluminum Case DC Connector: Copper Nose Lug Plug Suitable for Battery type: 84V 10A Li-ion Battery Charger AC Input: 100~120Vac, 50~60Hz Output Voltage: 84V Output Current: 10 Amp Battery Protection: SCP,OVP,OCP,OTP Charging Mode: Constant current - Constant Voltage - Floating Charge : Three-stage Intelligent Charging Charging efficiency: ≥85% Working temperature: -5 ℃ ~ +40 ℃ Storage temperature: -40 ℃ ~ +70 ℃ AC power cord, DC connector can be customized. Operating Instruction 1. Before charging, please connect the DC terminal to battery first, and then connect the AC terminal. 2. After charging complete, unplug the AC terminal firstly, and then unplug the DC terminal. 3. No charging or after charging complete, be sure to unplug the DC terminal and AC terminal. LED Indicator: LED 1 red: Power on. LED 2 red: Battery being charged. LED 2 Flash: Battery will be charged completely soon. LED 2 green: Battery has been charged completely. Package: 1* 84V 10A charger 1* US standard power cable 1* Operating manual ⛳⛳⛳
