WAOUKS 48 Volt 5 AMP Battery Charger for Yamaha Golf Cart Yamaha G19 G22 with 2 Pin Plug

⛳⛳⛳Specification: Product Name: 48V 5A Lead Acid Battery Charger Model: WA300-4805R-G19 Dimensions: 135x90x50mm Product Weight: 1.0 kg Color/Material: Red/Aluminum Case DC Connector: Yamaha G19 Charger Plug Suitable for Battery type: 48V Lead Acid Battery AC Input: 100~120Vac, 50~60Hz Output Voltage:48 Volt (55.2Volt) Output Current: 5 Amp Float Voltage:58.8Volt Battery Protection: SCP,OVP,OCP,OTP Charging Mode: Constant current - Constant Voltage - Floating Charge : Three-stage Intelligent Charging Charging efficiency: ≥90% Working temperature: -5 ℃ ~ +40 ℃ Storage temperature: -40 ℃ ~ +70 ℃ AC power cord, DC connector can be customized. Operating Instruction 1. Before charging, please connect the DC terminal to battery first, and then connect the AC terminal. 2. After charging complete, unplug the AC terminal firstly, and then unplug the DC terminal. 3. No charging or after charging complete, be sure to unplug the DC terminal and AC terminal. LED Indicator: LED 1 red: Power on. LED 2 red: Battery being charged. LED 2 Flash: Battery will be charged completely soon. LED 2 green: Battery has been charged completely. Package: 1* 48V 5A charger 1* US standard power cable 1* Operating manual 2* Fuse for replacing ⛳⛳⛳
