Timunr 2 Spool 25GPM Hydraulic Directional Control Valve, 3000PSI BSPP Ports Double Acting Hydraulic Valve with Joystick

Hydraulic Valve 2 Spool 25GPM 3000PSI BSPP Ports Hydraulic Directional Control Valve Specification: Ports: BSPP Inlet Port: BSPP G1/2 Center System: Open Temperature: -20-80℃ Outlet Port: BSPP G3/4 Relief Valve: Adjustable Nominal Pressure:20 Mpa Working Ports: BSPP G1/2 Filtrating Accuracy: ≤10 um Allowable Pressure: ≤1Mpa Nominal Flow: 25GPM (90 l/min) Max Operating Pressure: 3000PSI Features: 1. 3000PSI with adjustable pressure relief handle for maximum flow of 25GPM 2. Manual, pneumatic, electric, pneumatic, hydraulic, electric and other control modes can be used 3. Hydraulic directional valve is suitable for small tractor, tractors loader, light loader, log splitter, etc 4. Used to manage and guide the flow of hydraulic oil between hydraulic pumps and hydraulic cylinders, motors, tanks, etc 5. This product adopts durable cast iron material and hard chrome plated valve core design to make the product has a long service life Package Includes: 1 x 2 Spool Hydraulic Directional Control Valve
