TITAN- 12V DC Double Rack Mount Ventilation Cooling Fan for Fridge Vent and Ventilation Grille with Speed Controller (140mm(V2+))

APPLICATION -Refrigeration/ fridge cooling fan -Ventilation grilles -Motorhome vent fan SPECIFICATION TTC-SC22 -90mm Outline Dimension: 184 x 92 x 30 mm Fan Dimension: 92 x 92 x 25 mm Rated Voltage: 12V DC Rated Current: 0.48 A Power Consumption: 5.76 W Rated Speed: 500~2600 RPM Airflow: 106 CFM Static Pressure: 0.12 Inch H₂O Noise Level: 28 dBA Bearing Type: Two ball Life Time: 50,000 Hours TTC-SC22(B) -120mm Outline Dimension:240x 120 x 30 mm Fan Dimension: 120 x 120 x 25 mm Rated Voltage: 12V DC Rated Current: 0.56 A Power Consumption: 6.72 W Rated Speed: 2000 RPM Airflow: 121.13 CFM Static Pressure: 0.12 Inch H₂O Noise Level: <32.9 dBA Connector: 3-PIN Bearing Type: Two ball Life Time: 50,000 Hours SPEED CONTROLLER Outline Dimension: 85 x 37x 15.5mm Input Voltage: 12V DC Output Voltage: 7~13.8V DC Max Output Current: 1A Temperature Measuring: 20°C~ 45°C (500~2600RPM)
