TGGKKPARTS 2Pcs Tail Light Whip Power Harness Adapter Splice Pigtail Jumper for 2012-2023 Can Am Maverick X3, Max, X-DS for Powering LED Whips Brake Lights License Plate Lights Taillight

Tail Light Whip Power Harness Adapter Splice Pigtail Jumper Fitment: for Can Am Maverick X3, Max, X-DS 2012-2023 NOTE: DOES NOT FIT 2016 & Newer Can-Am Maverick 1000R X-RS Turbo. Instructions for use: You can use this at either tail light and can use two per vehicle if you want to power a whip on both sides. This Must Be Plugged In Directly At The Tail Light. It Will Not Work Plugged In Anywhere Else. Wiring: The red and yellow wires are both power wires. You only need to use ONE of them. You can cut off the unused one and wrap the end in electrical tape. Red will provide 12v any time the key is on. Yellow will only provide 12v when the brake pedal is pressed. Use the red wire to power accessories such as whips and license plate lights. Use the yellow wire to power additional brake lights. Use the black ground for all applications. Package Includes: 2Pcs Tail Light Whip Power Harness Adapter Splice Pigtail
