Supreform IP68 Waterproof Universal 12V 24VDC Metal Case Digital Wired Keypad for Garage Door, Gate Opener and Access Control Systems

Important Note: ★The Supreform digital metal case wired keypad is universal for your existing garage door opener & gate opener. ★You can attach it to the opener directly if your garage door/gate opener has a terminal for connecting a universal normal open dry contact wall push button. ★If the opener is intended to be used with the dedicated wall console, then you need to open the wall console and solder the output wires to the PCB of the wall console. In this situation, you must have the skill of soldering. You can send the photo of the PCB to us, and we will draw a wiring diagram for you. ★The card type which can be used with the keypad is 125KHz EM-ID card. 1.Product Description: The keypad is designed for outdoor use with an extra high protection degree IP68. The keypad can be powered by wide range input voltage 12-24VDC. Backlight of the keys makes it’s easy to operate at night. The output delay time of the relay is adjustable from 0.02 second to 99 seconds. Three working modes optional: “Code”, “ID Card”, “Code + ID card”. The keypad supports maximum to 2000 users - Code or ID card . You can program more standard ID cards to the keypad if needed. We guarantee to answering all your questions within 24 hours. 2.Technical specifications: Rated Input Voltage: 12-24VDC Standby Current: 30mA Operation Current: 60mA Load of the Output Relay: 2A 30VDC Maximum Users: 2000 Ambient temperature: -49-140°F Format of the Access Code: 4 digits Code 3.Contents: 1 x Wired Keypad; 1 x User Manual; 1 Set of Installation Accessories
