SJZBIN 5PCS High Power MOS Pipe Field Effect Tube Trigger Switch Driver Module PWM Regulation Electronic Control Board DC 5V-36V Continuous Current 15A

1.Features High reliability and availability: adopts dual MOS parallel active output, small internal resistance, high current and high power, meets the use requirements of most devices, realizes the easy control of high power devices. Trigger signal source: digital high and low levels (DC3.3V-20V), can be connected to microcontroller IO port, PLC interface, DC power supply, etc., can be connected to PWM signals, support for signal frequency 0-20KHZ. Output capacity: DC 5V-36V, continuous current 15A at room temperature, power 400W, auxiliary heat dissipation conditions, the maximum current up to 30A. 2.Specifications Model: High-power MOS tube field effect tube trigger switch driver module PWM regulation electronic switch control board Product dimensions: Length 34mm/1.34in, width 17mm/0.67in, height 12mm/0.47in, DC 5V-36V continuous current 15A (maximum current up to 30A) power 400W 3.package contains 5pcs high-power MOS tube field effect tube 4.Tips When first powered on, it is recommended to use an adjustable power supply to slowly ramp up the voltage, monitor the drain-source voltage, gate voltage and current to confirm that there is no abnormality before putting it into normal operation. After a long period of operation, regularly check the heat dissipation system, solder joints and component temperature rise, to prevent aging caused by failure.
