SAPHUE SSH-Coil Splitting Electric Guitar Pickguard Two Mini Humbucker + ONE Humbucker(9K/9K/15K)+Silence Switch Loaded Prewired Scratchplate (Black-Black)

Description: 100% Brand new, never used Item 100% like the picture shown Pickguard and Two Mini Humbucker + one Humbucker Switch is a 5 way switch and the wiring is one volume and two tone controls With three 2 way on/on switch, can Coil Split the pickup With Silence Switch Magnet: Ceramic. D.C. Resistance: Neck and Middle: 9K (splitting coil 4.5K) Bridge: 15K (splitting coil 7.5K) Four conductor wires, Black wire is hot, green wire is ground, red and white is for splitting coil 11 screw holes As with any pickguard, some modification may be necessary for exact hole alignment, as there are many different hole patterns. Material: PVC Pickguard and Copper Coil Pickup Pickguard Colour: 3 ply PVC, white or Black, please select the one you need Package Include: 1 x Guitar Loaded Pickguard Note: Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
