Renogy 10A Male and Female Connector Waterproof in-Line Fuse Holder, w, Black

Description This product is a 10A fuse embedded in a waterproof fuse holder and features MC4 connector cables on each end. Designed to provide complete single circuit protection to your solar array, it utilizes fuses to prevent large currents from damaging the solar panels. Specifications Renogy 10A MC4 Solar In-Line Fuse Holder Waterproof w/ Fuse Rated Current: 10A Rated Voltage: 1000 V DC Test Voltage: 6000V (50Hz,1 min) Degree of Protection: IP2*/IP67 Suitable Connector: MC4 Connector Contact Resistance of Plug Connector:1mΩ Insertion Force / Withdrawal Force: ≤50N / ≥50N Contact Material: Copper, Silver Plated Fuse Can Replace Insulation Material: PPO Temperature Range: -40 to +125°C Weight: 1.23 oz Dimensions: 4.8 x 0.8 x 0.8 In Safety tips For protection against electric shock, PV connectors must be isolated from the power supply while being assembled or disassembled. The end product must provide protection from electric shock. Unplugging under load: PV plug connections must not be unplugged while under load. They can be placed in a no load state by switching off the DC/AC converter or breaking the AC circuit interrupter. Plugging and unplugging while under voltage is permitted. Disconnected connectors should be protected from dirt and water with sealing caps. Warranty Information 1-year material warranty We sell entire home/business solar system both on grid and off grid, including racking, inverters and other system components. Please call us 909-517-3598 and extension sales.
