Reciprocating Cycle Linear Actuator, DC 24V Adjustable Telescopic Rocker Arm Mechanism Gear Motor with Speed Controller Regulation Adapter (2cm-8cm/45RPM)

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• 【Specifications】Name:Reciprocating Linear Actuator;Input voltage: AC100-240V,50Hz/60Hz; Working voltage: DC24V;120rpm.The reciprocating cycle linear actuator can be continuously reciprocating,metal gears make movement more smooth.
• 【Speed&Torque】The pushing and pulling force is mainly provided by the motor. At the voltage of 24V, the maximum speed is 120rpm, and the Torque is 2-17lbs. Different strokes and speeds generate different torques. The larger the stroke, the smaller the torque, and the smaller the speed, the lower the torque
• 【Gear motor】 Adopts high-quality pure copper wire motor and integrated heat-treated gearbox, with low heat generation, high power, multi-stage reduction, metal gears, higher strength and longer service life. Voltage: 24VDC, 120rpm, maximum torque 25kg/cm, hole spacing 50x50mm, shaft diameter 8mm, weight 0.5kg (1.1lb), rated current 0.6A, length and width 60x102mm (2.36 "x4")
• 【Speed Controller】Upgraded Speed Controller add switch buttons, so that the reciprocating motor can be used or stopped directly through the button, making it more safe and more convenient to use
