RV Fridge Circuit Board, 3316348.900 RV Fridge Refrigerator Circuit Control Power Module Board for Dometic DM2652 DM2662 DM2682 DM2872 DM2882 RM2652 RM2351 RM2451 RM2554 NDM1062 NDR1062 DMA4061

Features

• [COMPATIBILITY] This RV fridge circuit board is suitable for Dometic models: DM2652 DM2662 DM2672 DM2682 DM2663 DM2852 DM2862 DM2872 DM2882 DM3862 DM2852lbx DM2862rbx RM2652 RM2807 RM 2351 RM2354 RM2451 RM2454 RM2551 RM2554 RM2620 RM2662 RM2820 RM2852 RM2862 NDM1062 NDR1062 DMA4061 DMA4064.
• [REPLACEMENT] Package includes 1 pcs RV Fridge Circuit Control Board of 120VAC, 3.5A,60Hz and 12VDC, 1.9A, and the replace part numbers of this RV power module board are 3316348.900 3316348.000 3850712.013.
• [FEATURE] The RV refrigerator circuit board is designed with 7 ports and is made of quality materials for durability, reliability, and has stable performance of moisture resistance and a long service life.
• [FUNCTION] The power module circuit board is a lower control board replacement for gas absorption refrigerators with integrated propane enabled ignition. The lower control board is the main circuit board on the refrigerator that controls the ignition, propane operation and power to the AC components.
• [DETAILS] Fuse Back Cover description: P1-Connected to upper control board, P2-Thermistor, P3-Connected to gas valve, J2-Connected to indoor lighting/climate control, J4-Positive 12V DC from terminal block, J5-AC line voltage (black), J6-AC neutral (white), J7-AC neutral output to AC heater, J8-AC line output to AC heater switch side, J10-Negative to chassis ground.
