RC CH3 Control Switch,3 Channel On/Off LED Lamp Control Panel System Breath Flash Mode 6V for 1/10 1/8 RC Car Truck Crawler

Note:Please make sure that the remote controller have a 3CH function button.Otherwise it does not work. Compatible with HSP Traxxas Tamiya CC01 4WD Axial SCX10 1/10 1/8 RC Car Truck Crawler. After connect to the receiver third channel(CH3), you can control the light freely. Small size and lightweight, it won't add extra burden on RC car. Replacement parts for rc rock crawlers,and is a good choice for RC car fans. Material: Metal, Plastic Powered by: Battery Input: 5-12.4V/1A Type: Functional Switch(On/Off, Breath mode, Flash mode) Wire Length: Approx. 22cm/ 8.66inch It can connect 4 set led lights,there are 1.2.3.4 number on the control panel.1 and 2 are in parallel relationship,3 and 4 are in parallel relationship. It can be understood that the output lamp group is 2 groups and 4 ports. Each time the 3 channel switch is toggled or pressed, the cycle changes: When power supply on, 1 & 2 , 3 & 4 light off →→ 1 & 2 to light up, 3 & 4 light off →→ 1 & 2 to light off, 3 & 4 light up →→ 1 & 2 to light up, 3 & 4 light up →→ All light breathing mode open →→ All light breathing mode open →→ All light flashing mode open →→ 1 & 2, 3 & 4 are light off....cycle. Package includes: 1 * RC CH3 LED Light Lamp Control Panel
