Qolekog DC 24V Solenoid Valve 1/4" NPT 2 Way Normally Closed Air Valve Electric Solenoid Valve
Qolekog DC 24V Solenoid Valve 1/4" NPT 2 Way Normally Closed Air Valve Electric Solenoid Valve
Description
Performance Parameter: Port Size : 1/4"NPT Voltage: DC24V Response Time: Less than 20 ms Coil Duty: 100% ED (Continuous Duty) Operating Temperature: -10 to 80 °C Seal Material: NBR (Buna N) Armature Tube Material: Brass Body Material: Anodized Aluminum Plunger & Spring Material: Stainless Steel Power: 6.5W Service Media: Air, Gas, Liquid, Water Valve Type: 2 Way Normally Closed (Power on valve opens, power off valve closes) Flow Rate: 0.23Cv (Fluid Flow), 22 SCFM at 100 PSI (Air Flow) Operating Pressure: 0 - 101Psi (Suitable for vacuum environments)
Item Details
Pickup Location
7440 Dean Martin Dr Suite 204
Las Vegas, NV, 89139
Quality
brand
QolekogEstimated Retail Price
$10.99
color
Blacksize
1/4"NPTBuyers Premium
15%
Inventory Number
1048979126
Found in
Features
- Coil load of the pneumatic solenoid valve supports 100% ED.You can maintain long-term power on operation.
- Working pressure range 0-101Psi.Vacuum environment can work normally.Normal work temperature 14~176℉ (-4~80℃). IP65 dustproof and waterproof grade
- Volt:DC24V Port Size:1/4 inch NPT male thread. Flow Rate: 0.25Cv (Fluid Flow). Suitable for inert gases such as air
- The solenoid valve defaults to the closed state and opens when powered on.The wire has no positive or negative poles.
- The solenoid valve is a one-way valve.Please Install the solenoid valve correctly according to the flow direction identification, otherwise the valve will not be able to close. (The flow direction is marked on the packaging box)
