Padarsey Upgraded Wireless Rear View Camera with 7'' LCD Wireless Reversing Monitor Display for Heavy Machinery

Product Description Monitor Specification: LCD size: 7inch; Resolution:800x480; Radio Frequency:2.4GHz; Receiving sensitivity:-89dB; System Format:PAL/NTSC; Power Supply:DC7-30V, 12 recommended; Operating temperature:-20~+70°C, RH90%; Storage temperature: -30~+80°C, RH90%. Camera Specification: Inpu tVoltage:12v-24v, 12v recommended; Operating current: 360 MA‑‑12v daytime/ 460MA—12v night； 200MA—24v daytime/ 270MA—240v night IR distance:8~10M Video format:PAL/NTSC Connecter: DC IRCUT: Built-in,auto-switch Sensor:1/4.5''CMOS Resolution:640x480 RadioFrequency:2.4GHz Power：28dbm IP Rating: IP 67 Aluminum alloy shell and waterproof design suitable for outdoor use. Package included: 1x 7 inch LCD Monitor 1x Color Digital Cameras 2x 2.4G antennas 1x Bracket 1x double sticker 1x User Manual 2x Power cable TroubleShooting: NO Image or NO Signal: Please pressV1/V2 button to adjust to AV2. Please press LOOP button to adjust to "VIDEO CH D". Please make sure antennas are plugged on both monitor and camera. Please make sure monitor and camera are within signal reception range. You can shorten the distance between monitor and camera, or adjust the angle of antennas to find the best signal reception position.
