PDLC Switchable Smart Film Electric Smart Glass Film Adhesive All Day Privacy Protection Window Sticker, 6Inch x 12Inch

PDLC is a membrane-based product that combines rod-shaped liquid crystals with prepolymers and adheres to transparent conductive substrates, so it has both liquid and crystal characteristics, as well as significant optical and electrical properties. In the absence of an electric field, its molecules are arranged disorderly, making it opaque, and under the action of an electric field, the molecules are arranged orderly along the direction of the electric field, making it transparent. By controlling the electric field, it can be transformed between transparent and opaque states. So it is opaque when power off, it is transparent when power on Specifications: Material: PDLC(Polymer Dispersed Liquid Crystal), Imported Liquid Crystal and ITO Film Color: Translucent White Size: 6”X12” (And any size can be customized, want other size, please contact us) Features: Self-adhesive, anti uv, heat control, anti aging, anti fade, anti shatter, energy saving, environmentally friendly Haze: ON: <7%, OFF: >90% View Angle: ON: around 150° SHGC: ON: 0.78, OFF: 0.06 IR Blocking: ON: >30%, OFF: 90% UV Blocking: ON: 90%, OFF: 99% Response Time: ON to OFF: <20ms Power Consumption(On): <5W/㎡ Thickness(N/A): 0.54mm Service Life(Indoor): More than 10 years Operating Temperature(ON to OFF): -20℃ to 70℃ Transmission/Parallel Light: ON: About 84%(±1) , OFF: <1 Wide Application: Office doors and windows, meeting room, reception room, private room, wash room, bathroom Medical wards, operating rooms of hospitals, monitoring rooms, police station, court ect. jewelry shop, museums, insurance counters, automatic equipment ect. Large-scale projection screens Any place which needs 24 hours privacy Package Includes: 1 x PDLC smart film 1 x power supply
