NEWTRY Hydraulic Ram Jack 50 ton Hydraulic Cylinder Low Profile Ram Jack Multi-Section 2.56” Stroke Lifting Cylinder Mini, Portable for Machinery, Bridge, Construction

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• ▷Technical Specifications---Tonnage: 50T | Stroke 1: 0.78” | Stroke 2: 0.9” | Stroke 3: 0.86” | Total stroke: 2.56” | Oil storage capacity: 113cc | Self height: 2.56” | Weight: 19.8lbs/5.5kg | Compression area: 0.087sq.in | Inner diameter 1: 1.18” | Inner diameter 2: 2” | Inner diameter 3: 3.18” | External diameter: 5.15’’X6.1”.
• ▷Multi - Section Design for Narrow Spaces---This low-profile hydraulic jack stands at just 2.8 inches in height, yet it has a stroke of up to 2.56 inch. Unlike regular jacks, its multi - section design enables it to be used in much narrower and lower spaces. It effectively maximizes the jack's stroke within the body height, allowing you to lift weights to a greater height. This makes it a more convenient and practical choice for various applications.
• ▷Durable Construction for Long-Term Use---This ram jack has a smooth surface with distinct ring marks, which not only ensure smooth lifting but also provide a good grip. The piston is treated with a blackening process, significantly extending its lifespan. This durable construction means you can rely on it for long - term use without frequent replacements.
• ▷Convenient Mounting Options---Featuring two pre-drilled holes, this multi - section jack offers convenient mounting options. Whether you need to install it in a workshop, these holes simplify the mounting process. Just note that after pressure release, the piston needs external gravity to retract.
• ▷Leak - Proof and Dust - Resistant Design---The joints of this hydraulic jack are equipped with a plastic dust - proof cap. It prevent oil leakage and keep dust away from the internal components, maintaining the jack's performance over time. This leak - proof and dust - resistant design ensures that the jack remains in good working condition.
