MECCANIXITY Pneumatic Air Cylinder Double Action MAL32X300 32mm Bore 300mm Stroke with Y Connector and 4Pcs Quick Fitting Set

Features

• The cylinder is a mechanical device that uses the power of compressed gas to generate force for reciprocating motion. It can be widely used in the drive of pneumatic and hydraulic systems, such as can pressing, crushing machines, can-making machines, pneumatic systems, printing tension control, automation control, robot, punch, and other pneumatic systems.
• Model: MAL 32x300; Material: Aluminum Alloy; Action Type: Double Acting; Rod Type: Single Rod; Bore: 32mm / 1.26"; Stroke: 300mm / 11.8"; Cylinder Middle Outer Diameter: 37mm / 1.46"; Port Size: G1/8; Piston Rod Thread: M10*1.25; Rod Two End Thread Size: M24x2mm; Cylinder Length: 440mm / 17.3"; Working Pressure: 0.15~1.0 MPa / 22~145 psi; Package Contents: 1 x Air Cylinder, 1 x Y Connector, 2Pcs x G1/8 to 6mm fitting, 2Pcs x G1/8 to 8mm fitting
• Made of aluminum alloy, the cylinder body is improved and durable, with no deformation, impact, and abrasion resistance with corrosion resistance and smooth operation. The sealing piston adopts a special-shaped two-way sealing structure. Improved sealing structure, good sealing, lubrication, and guiding performance.
• Connect the corresponding size air tube and connector to the corresponding air source and control unit, and connect the screw end to the part that needs to be driven
• Please pay attention to the size specification of the product
