Little Giant LGS-75/LG14AH Dual Voltage (115/230V) 3/4 HP Shallow Well Jet Pump/Tank Combo 16 GPM Cast Iron Pump with 14 Gallon Pressure Tank, Blue/White, 558932
Little Giant LGS-75/LG14AH Dual Voltage (115/230V) 3/4 HP Shallow Well Jet Pump/Tank Combo 16 GPM Cast Iron Pump with 14 Gallon Pressure Tank, Blue/White, 558932
Description
The Little Giant LGS-75/LG14AH 3/4 hp shallow well jet pump and 14 gallon tank combo is designed for wells down to 25' deep supplying fresh water to rural homes, farms and cottages. This combo comes pre-assembled for easier installation. The pump is dual voltage and suitable for 115-volt and 230-volt power sources. The pump comes factory set for 230-volt operation. To change to 115-volt operation following the instructions in the owner's manual. The tank comes pre-pressurized at approximately 20 psi for transportation. The tank must be set to 2 psi below the cut-in pressure. Since this system comes with a 30 psi pressure switch, the tank must be charged to 28 psi. To do this, use a bicycle pump to fill the tank to 28 psi. This system includes a 3/4 hp shallow well pump, 14 US gallon tank; 30/50 pressure switch; 1/4" MNPT back mounted pressure gauge, plastic foot valve and stainless steel hose with T-fitting connected to the pump and tank.
Item Details
Pickup Location
7440 Dean Martin Dr Suite 204
Las Vegas, NV, 89139
Quality
Auction closes
October 25, 2025 at 1:57 AM
Estimated Retail Price
$476.50
Buyers Premium
15%
Inventory Number
1056715454
Found in
Additional Details from the Manufacturer
This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing
brand
Little Giantcolor
Blue/Whiteweight
67.00 lbsMore features
- ALL-IN-ONE WELL PUMP SYSTEM: jet pump and pressure tank are factor assembled and ready to install; pressure tank comes charged to 20 PSI for transport and must be charged to 28 PSI
- BUILT TO LAST: heavy-duty cast iron casing and volute; glass-filled thermoplastic impeller and diffuser; steel tank with high-grade diaphragm water chamber
- INCLUDES: along with pump and tank, this system includes a factory pre-set 30/50 pressure switch, 1/4" MNPT back-mounted pressure gage, plastic foot valve, and stainless steel hose
- DUAL VOLTAGE MOTOR: for use with 115-volt or 230-volt power sources; comes factory-set at 230-volts but can be easily switched to 115-volt operation; ensure pump voltage is set to match power source
- SPECIFICATIONS: 3/4 hp, 28 running Amps; 45 starting Amps; 5200 Watts; 1-1/4" FNPT intake; 3/4" FNPT discharge; 16.7 gpm at 5' suction lift and 30 PSI; max: 65 PSI; 150' max head
