Kadimendium 4Pcs Near Field Probe EMI EMC Pre Certified Magnetic Field Test Tool Magnetic Field Probes Set 30MHz?3GHz KCR20B Magnetic Field Antenna

Feature : 1 . 30MHz 3GHz Frequency Response : The frequency response of the probe is relatively flat in the range of 30MHz to 3GHz and is used to measure the magnetic field in the development phase 2 . Comprehensive Function : Large diameter probes have high sensitivity but low directional resolution , while corresponding small diameter probes have low sensitivity but high directional resolution 3 . Without Burrs : Near field probe is one piece molding without burrs , possess smooth for surface and fluent installation 4 . Impact: Good quality ABS material , possess impact, scratch, environmentally friendly 5 . 4Pcs in Total : The package contain a total of 4pcs of probes , which can fully meet your using needs Specification : Item Type : Near Field Probe Material : ABS Operating Frequency : 30MHz to 3GHz Package List : 4 x Near Field Probe Note : In use , the large size probe is usually used to determine the approximate area where the interference source is located , and then the small diameter probe is changed to narrow the search range , and gradually identify the source of the interference magnetic field in the electronic module .
