KKnoon 150W 20A Adjustable Constant Current Electronic Load 2.4inch TFT Color Display 4 Working Modes USB Lithium Battery Capacity Monitor Tester Discharge Meter

Specifications: Name: Electronic Load Material: printed circuit board Load type: CNC electronic load Working voltage: 12VDC with 12 V, 1A power adapter Load voltage: 0-150VDC Load current: 0-20A Load power: 0-150W (max. 60W above 120V) Wiring method: A+ V+ V- A- four-wire system, downward compatible with two-wire system Maximum power measurement: 999.999Wh Maximum capacity measurement: 999.999Ah Cumulative timing range: ddd:hh:mm:ss (days:hours:minutes:seconds) Operating modes: four modes CC-constant current mode CV-constant voltage mode CP-constant power mode CR-constant resistance mode Overvoltage protecting: supports up to 150V overvoltage protections Overcurrent protecting: supports up to 20A overcurrent protections Over-power protecting: supports up to 150W over-power protections Limited voltage discharge: also called low voltage protections, support, default unlimited voltage discharge, set according to your needs Time limit discharge: support up to 99 hours: 59 minutes time limit discharge Heat sink: Alloy integrated silent heat sink, internal temperature ≥40°C or current ＞3A automatic operation External temperature measurement: connect NTC 3950 10K 1% temperature sensor to measure and display temperature from 0-100°C Chinese and English interface switching: supported Zeroing of total data: supported Voltage and current no-load nulling: supported Voltage open calibration: supported Current open calibration: Support Screen brightness adjustment: Support Screen hibernation standby setting: Support PC software online: Not supported Restore factory settings: Support Package size: 195 * 105 * 135mm / 7.68 * 4.13 * 5.31in Package weight: 625g / 1.38lb Packing List: 1 * Electronic Load 1 * Adapter 1 * NTC Sensor
