HiLetgo BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Arduino Current Limit

Instruction: This driver uses Infineon chips BTS7960 composed of high-power drive full H-bridge driver module with thermal over-current protection. Double BTS7960 H-bridge driver circuit, with a strong drive and braking, effectively isolating the microcontroller and motor driver! High-current 43A. Electrical performance: Model: IBT-2 Input voltage: 6V-27V Maximum current: 43A Input level: 3.3-5V Control method: PWM or level Duty cycle: 0-100% Input port: 1.RPWM: forward level or PWM signal input, active high 2.LPWM: Reverse level or PWM signal input, active high 3.R_EN: forward drive enable input, high-level enable, low level off 4.L_EN: Reverse drive enable input, high-level enable, low level off 5.R_IS: forward drive current alarm output 6.L_IS: Reverse drive current alarm output 7.VCC: +5 V power output, 5V power supply connection with the microcontroller 8.GND: signal common low end Package Included: 1BTS7960 43A High Power Motor Driver Module/ Smart Car Driver Module
