HeelAooRC 5.8G 1000mW 48CH VTX FPV Transmitter Input Voltage 7-26V Video Transmitter Power 25/100/200/400/1000mW for Long Range RC Airplane FPV Drone

Attention: Before powering on, please make sure toreliably connect the antenna, otherwise it will burn when powered on. VTX1000 will generate heat during use, which is normal. Please do not touch with your hands to avoid burns.The higher the power, the more heat it generates. The PCB uses high-end customized materials,and high temperatures will not bum out the circuit board.VTX1000 should be kept away from the flight control and in a ventilated position on the aircraft.The heat dissipation module should face upwards and be in a ventilated position in order to continuously dissipate heat. Default output: 5865MHZ(5.865GHZ)/1W Model:VTX1000 Frequency: 5645-5945MHZ Input voltage:7-26V Output voltage:5V/1A Channel:40CH Size:29MM*29MM/37.5MM*37.5mm Transmission power:PIT/25MW/100/200/400/1000MW Screw hole: 30.5*30.5MM/20.5MM*20.5MM Screw aperture: 3MM Weight:7.3g Packaging List: VTX1000 Board*1 Shock-absorbing ball *4 Fixed nylon column *4 Heat dissipation module *1 5.8G 5DB antenna *1 6P* 1.0MM plug cable * 1
