Furniware 30 Pack 3/4 Inch Overlay Soft Close Hinges for Face Frame Cabinet, Speed Control 4D Adjustment, Stainless Steel Kitchen Cabinet Hardware, 105° Open Concealed Self Closing Hinges

Features

• 4D Adjustment Structure(Vertical, Horizontal,Depth, Closing Speed) & High-Quality Mechanism (Soft Close) which slowly pulls the Door closed for a Smooth Silent Motion. Reduced closing speed keep little fingers safe and unwanted sounds from kitchen
• 30 Pieces 105 Degree Face Frame 3/4" Overlay Self-Closing / Soft Close Cabinet Door Hinge, 3/4" Overlay Hinges are useful for pairs of doors in the middle of a run of Cabinets. They're easily installed requiring minimal carpentry skills.
• Cup Diameter: 35 mm (1-2/5"), Depth of cup: 11.6mm(9/25"), Hole Distance: 45 mm(1-4/5"), Material: Cold-rolled Steel, Finish: Nickel Plated, Opening Angle: 105 Degree
• These types hinge an ideal choice for face frame cabinets. It's useful for kitchen cabinet doors, wardrobe, tv cabinets, bookcases, wine, and other luxury door connection
• HOW TO CHOOSE A HINGE - You need to pay attention to the thickness of the cabinet side panel(measure the distance the door panel overlaps the cabinet face) instead of the thickness of the cabinet door. You must choose the cabinet hinges that fit the side thickness of your cabinet. For example, if the thickness of the cabinet side panel is 3/4", then you should choose the corresponding 3/4" hinge
