FoxAlien XE-Ultra 8080 CNC Router Machine with NEMA 23 Closed-loop Stepper Motor, Large Size Benchtop Engraving Milling Machine for Woodworking, Aluminum, Acrylic, Carbon Fiber DIY Cutting

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• Mega-Scale 33"x33"x4.72" Workspace: Tackle ambitious projects with a super large XYZ working area (33x33x4.72in) and 5.3" pass height, engineered for large materials and complex designs.
• Industrial Rigidity & Precision: Equipped with 16mm ball screws (XY) and 12mm ball screws (Z) paired with HG-15 linear rails on all axes, ensuring smooth and high-accuracy movement. The heavy-duty 46×80mm aluminum frame ensures long-term stability and rigidity.
• 2.6 N.m Closed-Loop Stepper Motors: Featuring 60-86mm closed-loop stepper motors delivering powerful 2.6Nm torque with intelligent step-loss protection, maintaining high performance and precision even at high speed up to 5,000mm/min.
• Open Spindle Ecosystem: Total flexibility on spindle choices. Customize your setup—supports 65mm routers, FoxAlien 1.5kW VFD spindle, or FA20W/40W/80W engraving modules (65mm clamp included, spindle not included in the package).
• Industrial Inductive Limit Switches: All-axis sensors offer instant response (0.5ms response), anti-interference performance, and extended durability. Physical hard limits provide dual-layer collision protection.
• Smart 32-Bit Control Box: Features real-time stepper motor diagnostics via malfunction indicator lights for streamlined troubleshooting. There is a reserved port for 4th axis (coming soon).
