FLASH HOBBY 60KG Brushless Servo IP67 Waterproof Servo 14V High Torque Servo with Full Metal Gear for 1/8 1/10 RC Crawler Car Truck or Robotic Parts (270°)
FLASH HOBBY 60KG Brushless Servo IP67 Waterproof Servo 14V High Torque Servo with Full Metal Gear for 1/8 1/10 RC Crawler Car Truck or Robotic Parts (270°)
Description
Product Description: 270 Degree: Operation Travel: 135°±5 Limit angle: 270°±1 Torque/Speed: 48kg-cm/0.14sec/135° at 8.4V, 60kg-cm/0.11sec/135° at 14V 360 Degree: Operation Travel: 180°±5 Limit angle: 360°±1 Torque/Speed: 48kg-cm/0.14sec/180° at 8.4V, 60kg-cm/0.11sec/180° at 14V Specification: Control System: PWM Control (1500usec in the central point) Operation Voltage Range: 8.4V-14V Operation Temperature Range: -20C°~ +60C° Circle: ＞100w times without load Direction: Re-clock wise/ Pulse Travel 500→2500 μsec Diver type: Mos Drive Motor Type: Brushless motor Potentiometer Type: Magnetic encoding Amplifier Type: Digital Control Dimensions: 40x20x41.50mm Weight: 80g (without servo horn) Dead band width: 1 usec Ball Bearing: 2BB Gear Material: Metal Gear Case Material: Aluminum Case Connector Wire Length: 300MMJR Plug Connector Wire Gauge: 22AWG Wire Info (Brown): Negative Wire Info (Red): Positive Wire Info (Yellow): S Single
Item Details
Pickup Location
7440 Dean Martin Dr Suite 204
Las Vegas, NV, 89139
Quality
brand
FLASH HOBBYEstimated Retail Price
$62.00
color
270°size
DigitalBuyers Premium
15%
Inventory Number
1048974699
Found in
Features
- High Torque Servo: The maximum torque of servo is 8.4V up to 48kg/cm, speed is 0.14sec/135° and 14V up to 60kg/cm, speed is 0.11sec/135°
- Waterproof Servo: Equipped with waterproof black O-ring inside, the waterproof level is IP67, makes the RC steering servo can cross the stream and play in the rainy day easily
- High Precision: Design with dual ball bearings and advanced potentiometer, which ensure the high linearity and accuracy of the M60BHW servo
- Application: IP67 waterproof servo is ideal for 1/8 1/10 scale RC crawler cars, trucks, boats, robotic part and other remote control models
- High Quality: Full CNC AL 6082 aluminium shell with good heat dissipation performance. Package includes 1 x 14V metal gear servo, 1 x 25T servo horn and a set of accessories
