Ezcap 286 SDI Video Recorder, Recording from TV, Gameplay, Endoscope with HDMI/SDI Pass-Through

*Record 1080P video to USB disk ,HDD or SD Card directly. *Supports HDMI,SDI input,HDMI/SDI Pass through. *Support Line audio out and RTC(Real Time Clock) function. *With remote control-REC/STOP,Video Source and record quality switch,snapshot. *Support PC recording (Record and stream the video by software). *Encode:Hardware H.264 encoder, AAC Stereo. *Record format:MPEG4. *Record Quality:Max:18Mbps@1080P 30fps. *With Foot Switch slot, can control recording by foot pedal. It with a remote expand cable, so can set the device inside a metal case and can remote control it at same time. HDMI:Industry HD Camera, HD Medical endoscope,TV, Gameplay,etc SDI: HD Camera, HD Medical endoscope. Note:HDCP Contents cannot be recorded. Codec:Hardware H.264 encoder Storage Media: USB Flash Drive,Portable Hard disk,SD Card.(The exFAT format is not supported) Resolution: Input/Pass-through: 720x480 (60p),720x576 (50p),1280x720p (50p), 1280x720p(60p),1920x1080(50i),1920x1080(60i),1920x1080(24p),1920x1080(25p), 1920x1080 (30p),1920x1080(50p),1920x1080(60p) Capture: 720x480 (60p),720x576(50p),1280x720p(50p), 1280x720p(60p),1920x1080(50i),1920x1080(60i),1920x1080(24p),1920x1080(25p), 1920x1080(30p),1920x1080(25p),1920x1080(30p) Note:Upscaling is not supported. Record format: Video H.264, Audio:AAC Stereo Record quality:Max:18Mbps@1080P 30fps Record file:Max:2GB per file, with RTC(Real Time clock) Record place: MAX:140MB/Minute,8.4GB/Hour. Power supply: DC12V/3A Package Include: 1*ezcap286 SDI/HDMI Video Capture 1*DC Adapter(12V3A) 1*Remote Control 1*Remote expand cable 1*Software CD 1*User Manual
