EPEVER 40A MPPT Solar Charge Controller Max. PV 150V Solar Panel Charge Regulator with LED&LCD Display Double USB Port and MT50 Remote Meter Temperature Sensor RTS & PC Communication Cable RS485

Specification System voltage: 12/24VDC auto work Rated charge current: 40A Battery input voltage range:8-32V Max. PV open circuit voltage:150Vat Min operating environment temp; 138Vat 25 environment temp Max. PV input power : 520W/12V, 1040W/24V Working environment temperature:-20℃～+70℃ Self-consumption: ≤14mA(12V)；≤15mA(24V) Grounding: Common Negative USB interface: 5VDC/2.2A(Total) PRODUCT FEATURES: Recognize and upload the module driver automatically Modular design is convenient maintenance and upgrade LCD, LED, Relay, USB or RS485 module optional Multiple load control modes LCD and indicators to display operating data and status of the system RS485 port with industrial standard MODBUS open architecture Real-time energy statistics Relay design realize the perfect combination of inverter and controller Electronic Protections: Battery over discharge protection; Battery reverse polarity protection; Load short circuit protection; Load overload protection etc Accessories Description: 1> Remote Temperature Sensor (RTS300R47K3.81A): 3m length, Acquisition of battery temperature for undertaking temperature compensation of control parameters. 2> USB to RS485 cable CC-USB-RS485-150U USB to RS485 cable: USB to RS-485 converter is used to monitor each controller on the network using Solar Station PC software. The length of cable is 1.5m. 3> Remote Meter MT50 Can modify and monitor your controller 's parameters from a long distance. MT50 can display various operating data and fault of the system. The information can be displayed on a backlit LCD screen, the buttons are easy-to-operate, and the numeric display is readable. Package: 1x EPEVER TRIRON4210N solar Controller 1 x Remote Meter MT50 1 x RS485 1 x RTS 1x User Manual of controller
