DC 775 Motor 12V-24V 6000-12000RPM 775 Electric Motor Double Ball Bearing High Torque Large Power Low Noise DC Motor with Bracket DIY for Mini Angle Grinder Table Saw Drill Electrical Tools

Features

• Usage Tips: The power supply voltage is DC 12V-24V. The starting current must be above 10A or more. It is recommended to use a power supply such as a switching power supply or a battery. Motor is a high speed motor, please securely connect the tool accessories. Prevent accidents. Please connect the polarity correctly (the terminal near the red silicone point is positive), otherwise it will damage the motor.
• Quality Material: This 775 brushed magnet motor adopts integrated forging case, metal back cover, round shaft to increase concentricity, front and rear double ball bearings, internal pure copper winding rotor, 2pcs fan-shaped powerful magnet, built-in cooling fan, high matching Magnetic protection ring, Use high-quality carbon brushes.
• Features: This 775 DC motor has the characteristic of high speed, Large torque, low noise, built-in cooling fan, small size, durable and long service life. It can rotate CW and CCW. Default with motor mounting bracket and 2-In-1 3.2in length flat and Phillips screwdrivers. it is a good choice for DIY power tools and equipment.
• Moter Specification: Rated Voltage: 12V-24V; Rated Speed: 6000-12000 ± 10% RPM; No-load current: about 0.5A; Stall current: 10A or more; Motor body diameter: 1.65", Motor body length: 2.62"; Front output shaft length: 0.63 ", Rear output shaft length: 0.27", Shaft diameter: 0.196"; Mounting hole size: M4, Mounting Hole Pitch: 1.14"; The specification of L- bracket: Length: 1.97", Width: 2.0", Height: 2.0", Mounting hole diameter: M4, Thickness of bracket: 0.118".
• Wide Application: This electric motor is perfect replacement for Sea-Doo Spark iBR actuator reverse gate motor or DIY for other electrical tools, eg. small electric drill, angle grinder, small cutting machine, small table saw, paper shredder, electric fans, electric screwdriver, electric cleaners, electric fan toys, juice machine, vacuum etc. and other hand tools, power tools. Tips: if you need Multifunctional Electric Drill Conversion Kits, please purchase in "B0B2D6WWM1".
