CBB65 Round Dual Run Circular Start Capacitor, 50 + 3 uF/MFD ±5% 370V/440VAC Combination Capacitor for Compressor AC Motor Run Fan Start Condenser Straight Cool/Heat (50 + 3 uf)

This capacitor is used for start-up and operation of AC motors with frequency of 50Hz/60Hz such as Industrial Grade Replacement for Central Air-Conditioners, Heat Pumps, Condenser Fan Motors, and Compressors. It is small in size, lightweight, heat resisting and anti-explosion. Round capacitor can be used to substitute oval shape one with the same MFD AND Volt specs. A 440 volt capacitor can be used in place of a 370 volt, as it is build better, but the 370 can't be used in place of a 440 volt. Dielectric Material: metallized polypropylene film Executive standard: GB/T3667-2005 Product features: Climate category: 40/70/21 or 40/85/21 Volume deviation: ±5% Insulation resistance: ≥3000S (MΩ.μF) Loss tangent: tgδ≤0.002 (50Hz～100Hz) Rated voltage: 370V/440V AC Frequency: 50 / 60Hz Safety rated: 10,000 AFC Replacement for 97F9895 , Z97F995 , 97F9895BZ3 , 27L880 , TRCD455 , TRCFD455 , PRCFD455 , 27L889 , 97F9851 , 97F9851S , 12788 , RC0114 , Z97F9895 , 97F9895 , TT-CAP-45/5/440R , HC98KA046 , TP-CAP-45/5/440R , CAP050450440RT , HC98JA046 , HCKS450D050R440Z , 00662441180262
