BlueStars 4681EA2001T Washer Drain Pump Motor for Kenmore LG Washers - Replacement AP5328388 4681EA1007G for drain pump washing machine wm2101hw wm3270cw wm3431hs wm3770hva wm2075cw

Features

• 100% LIFETIME PROTECTION: Enjoy reliable performance with our lifetime protection, ensuring that your product will always be covered for any defects or issues that may arise.
• REPLACEMENT PART NUMBER: The 4681EA2001T Drain Pump replaces part numbers: AP5328388, 2003273, 4681EA2001T, 4681EA1007D, 4681EA1007G, 4681EA2001D, 4681EA2001N, 4681EA2001U, PS3579318, EAP3579318. The 4681EA2001T washer drain pump motor helps remove water from the washing machine, activating after the spin cycle reaches a consistent speed for a set duration. This LG drain pump motor replacement is crafted from durable, high-quality materials and has passed rigorous manufacturer testing to meet OEM standards, ensuring reliable and long-lasting performance.
• 4681EA2001T Washer Drain Pump. Detail Specs - Flow rate: 45L/Min - Rated voltage: AC220-240V/110-120V - Rated frequency: 50/60Hz - Power: 85W - Current: 1.4A - Insulation: Class F - Rotor rotation: 3000 rpm. No leakage under 0.03Mpa hydraulic pressure. This washer drain pump features an integrated impeller, which is not available as a separate part, and is lubricated with high-quality oil to ensure quiet and smooth operation. The upgraded metal components resist rust, extending the pump's lifespan. This part fixes the following symptoms: 1. Will not drain | 2. Pumps but will not spin | 3. Noisy | 4. Leaking.
• Before installing the 4681EA2001T washer drain pump, first disconnect the power and water supply. Using a Phillips screwdriver, remove the drain cover from the cleaner, then disconnect the wiring harness and the two hoses from the drain pump assembly. There are two washers on the tilted back leg-loosen the screws and remove the drain pump. Install the new pump, tighten the screws, and reconnect the hoses, wiring harnesses, and gaskets.
• Compatible models: [LG] CW2079CWD; CW2079CWN; WD-3243RHD; WM3431HW; WM3455HS; WM3470HWA/00; WM3470HWA; WM3470HVA/00; WM3470HVA; WM3455HW; WD-3245RHD; WD-3274RHD; WD-3274RHD; WM0001HTMA; WM0532HW; WM0642HS; WM0642HW; WM0742HGA; WM0742HWA; WM1333HW; WM1355HR; WM1355HW; WM1377HW; WM1388HW; WM1811CW; WM1812CW; WM1814CW; WM1815CS; WM1832CW; WM2010CW; WM2011HW; WM2016CW; WM2016CW/00; WM2016CW/01; WM2032HS; WM2032HW; WM2042CW; WM2050CW; WM2050CW/00; WM2075CW; WM2077CW; WM2101HW; WM2140CW; WM2233HD; etc
• Compatible models: [LG] WM2450HRA; WM2455HG; WM2455HG/00; WM3431H; WM3431HS; WM2455HW; WM2487HRM; WM2487HRMA; WM2487HWM; WM2487HWMA; WM2487WHM; WM2496HSM; WM2496HWM; WM2497HWM; WM2501HVA; WM2501HWA; WM2601HL; WM2601HR; WM2601HW; WM2650HRA; WM2650HWA; WM2655HVA; WM2677HBM; WM2677HSM; WM2677HWM; WM2688HNM; WM2688HNMA; WM2688HWM; WM2688HWMA; WM2701HV; WM2801HLA; WM2801HRA; WM2801HWA; WM2901HVA; WM3001HPA; WM3001HRA; WM3001HWA; WM3050CW; WM3070HRA; WM3070HWA; WM3080CW; WM3080CW/00; WM3150HVC; WM3150HWC; etc
• Compatible models: [LG] WM3370HWA/00; WM3370HWA/01; WM3477HS; WM3477HW; WM3485HWA; WM3488HS; WM3488HW; WM3550HVCA; WM3550HWCA; WM3570HVA/01; WM3575CV; WM3575CW; WM3632HW; WM3670HRA; WM3670HRA/00; WM3670HVA; WM3670HVA/00; WM3670HVA/01; WM3670HWA; WM3670HWA/00; WM3677HW; WM3770HVA; WM3770HWA; WM3875HVCA; WM3875HWCA; WM3885HCCA; WM3885HWCA; WM3987HW; WM3988HMA; WM3988HWA; WM3997HWA; WM3997HWA/00; WM4070HVA; WM4070HWA; WM4270HVA; WM4270HVA/00; WM4270HVA/01; WM4270HWA; WM4270HWA/00; WM4270HWA/01; etc
• Compatible models: [Kenmore] 796.40021.900; 796.40272.800; 796.40272.900; 796.40272900; 796.40311.900; 796.40311900; 796.40318.900; 796.40318900; 796.40441.900; 796.40448.900; 796.40512.900; 796.40518.900; 796.41002610; 796.41002612; 796.41003610; 796.41003611; 796.41022.900; 796.41028.900; 796.41029.900; 796.41072310; 796.41072311; 796.41073310; 796.41073311; 796.41162.211; 796.41162410; 796.41162411; 796.41172210; 796.41172211; 796.41172212; 796.41182310; 796.41182311; 796.41262610; 796.41262611; etc
• Compatible models: [Kenmore] 796.41548.110; 796.41548210; 796.41549.110; 796.41549210; 796.41582412; 796.41583.211; 796.41583410; 796.41583411; 796.41682610; 796.41683610; 796.41722.010; 796.41722000; 796.41728.010; 796.41728.900; 796.41728000; 796.41728900; 796.41962610; 796.41963610; 796.41982410; 796.41983410; 796.42192.900; 796.42198.900; 796.42199.900; 796.48842.800; 796.48842800; 796.48852.800; 796.48852800; etc
• Compatible models: [Kenmore] 796.41372210; 796.41372211; 796.41379210; 796.41382410; 796.41382411; 796.41383410; 796.41383411; 796.41392510; 796.41392511; 796.41393510; 796.41393511; 796.41393610; 796.41472210; 796.41473210; 796.41482.211; 796.41482410; 796.41482411; 796.41483410; 796.41483411; 796.41532.110; 796.41532210; 796.41538.110; 796.41542.110; 796.41542210; etc
