Bisida 16S BMS 60V 100A Li-ion PCB Protection Board with Balance Wire and NTC,Ten Functional protections, Common Port, for Solar Energy Storage, Balance Car Lithium-ion Battery Pack (16S 60V 100A)
Bisida 16S BMS 60V 100A Li-ion PCB Protection Board with Balance Wire and NTC,Ten Functional protections, Common Port, for Solar Energy Storage, Balance Car Lithium-ion Battery Pack (16S 60V 100A)
Description
Product size: 80mm*160mm*17mm Voltage Value: 60V Charger Voltage: 67.2V Working Current: 100A Charging current: Recommended below 30A Temperature protection: -20 ~ 70 ℃ Applicable Battery: 3.7V lithium ion Battery (Single Cell) Instantaneous CurrenT: 3 to 5 Times the working current. Package Contents: Battery Protection Board*1 Cable*1 If you have exact requirers, you need to batch, or customize the Please Communicate with the Seller to Confirm Please note: Our products use the integrated IC solution. It means that the SOC accuracy of the BMS is very high, and the voltage of each string will be collected. It must be required that the voltage, internal resistance, and capacity must be the same height during assembly, otherwise the BMS will disconnect and protect (disconnection protection function). This product is an industrial semi-finished product, which needs to be repaired and assembled by people with professional electrical knowledge. Thank you for your understand.
Item Details
Pickup Location
7440 Dean Martin Dr Suite 204
Las Vegas, NV, 89139
Quality
Auction closes
September 1, 2025 at 4:11 AM
brand
BisidaEstimated Retail Price
$43.99
Buyers Premium
15%
Inventory Number
1054374786
Found in
Features
- MULTIPLE PROTECTION Bisida's BMS has a variety of protection functions, such as over charge protection, over discharge protection, over current protection, short-circuit protection, temperature protection, isconnect protection, Voltage balance(passive balance), etc.
- OPERATING TEMPERATURE Bisida's BMS supports (3.7V) lithium-ion battery charging and discharging in zones from 2.65V to 4.25V, with low temperature protection up to -20°C and high temperature protection up to 70°C. Different voltages and currents have different parameter details. Confirmation required.
- NOTICE Before installing the BMS protective board, it is necessary to match the voltage, capacity, and internal resistance (the voltage difference between the battery per section is not higher than 0.05V, the difference between the internal resistance is not more than 5MΩ, and the capacity difference is less than 30mAh). Otherwise the battery pack will not be able to charge.
- WIRING METHOD The wiring methods of Common ports of BMS: B- connection battery pack negative , C- connection charging negative/output negative. All the positive electrodes are the total positive pole from the battery pack.
- EXCELLENT SOLUTION Bisida's BMS is manufactured using excellent protective integrated circuit IC and excellent Mosfet, making it robust, long-lasting and reliable
