BD Diesel Exhaust Manifolds Ford F-150 3.5L Ecoboost 2011-2016

The 2011-2016 Ford 3.5L has an inherent design flaw where not all of the OE stud locations are utilized by the OE manufacturer which leads to warped exhaust manifolds, broken exhaust studs and blown manifold gaskets. The cylinder head on Fords 3.5L Gas Ecoboost has threaded holes for 11 exhaust studs to be used, however the OE manifold only utilizes 8 of those stud locations.BD has designed a manifold that not only utilizes all 11 stud locations, but also improves exhaust flow and has improved durability, the way it should have come from the factory. BD's Ford 3.5L exhaust manifolds are made from thicker-walled high silicone ductile iron designed to resist thermal warping. Each manifold has been gasket matched and designed using 3D flow simulations to optimize flow from the engine to the turbocharger.Each kit includes 22 exhaust spacers and 22 class 8.8 studs designed to further improve thermal durability

15mm longer exhaust studs + spacers

36-Months

Each manifold gasket matched and designed using 3D flow simulations to optimize flow

75,000 Miles

Utilize 3 additional exhaust stud locations

New studs, spacers, and nuts included

Suggest optional 1043002 addition parts kit for easier install

BD Thick wall high-silicon ductile cast iron resists thermal warping
