Alpha 65 Degree 4 Port Antenna (Directional)

Alpha Wireless panel antenna, AW3161-M-F-V2, 3300 – 3800 MHz, 65 Degree Sector Antenna, 18 dBi, MET, 31” (783mm) x 11” (280mm) The Alpha Wireless 3300 – 3800 MHz AW3161-M-F-V2 is a high performance 4-port, 65 degree single band sector panel with manual electrical variable tilt. The antenna incorporates advanced phase-shifter technology to suppress all upper side lobes above the main beam, for all tilts and frequencies. The AW3161-M-F-V2 eliminates interference in LTE networks with over 20 dB of upper side lobe suppression and 30 dB front to back ratio. This improves cell edge performance and enables high levels of spectral efficiency. This antenna’s consistent beamwidth and null filling below the main beam provides consistent coverage near-to and far-from the access point. The Alpha Wireless AW3161-M-F-V2 provides ±45 degree slant polarization and supports 4×4 MIMO. This panel antenna delivers an impressive 18 dBi gain and optimized patterns for 3.5GHz CBRS and C-band deployments.
