ANMBEST 2PCS USB 3.1 Type C Panel Mounting Waterproof Connector, IP67 24 Pins Female to Female PA6BG33 Housing Double Head Adapter with Waterproof/Dust Cap

The TYPE C signal panel connector is a Female/Female Couple. Using the standards based TYPE C connection system insures compatibility with existing hardware. The coupler maintains the continuity offering protection from EMI/RFI interference. Specifications: Number of cores: 24 PIN Waterproof rating: IP67（with Waterproof/Dust Cap） Connection type: TYPE-C Flame retardant rating: UL94V-0 Connection method: plug type Case wall thickness: Threaded type: >2mm, through-hole type: 0.3~7mm Mounting Hole Size: 24mm Thread size: 24*1.5 Connector transmission classification: USB3.1 Transmission speed range: 5Gbps Electrical parameters: Rated current: 5A Rated voltage: 12V Insulation resistance: ＞500MΩ Compressive strength: AC1000V 50HZ or 60HZ for 1 minute Contact resistance: ＜10MΩ Material: Shell: PA6BG33 Socket contact pin: phosphor copper Contact pin gold plating thickness: 6u inch Waterproof rubber ring: silicone Environmental conditions: Working temperature: -40～120Celsius Storage temperature: -25～85Celsius Atmospheric pressure: 86～106kPa Relative humidity: ≤90% RH Tips: When the transmission speed is only 30Mbps, please insert the data cable in reverse, and the transmission speed will reach the expected 5Gbps. Package Included: 2x Waterproof TYPE C Connector 2x Waterproof/Dust Cap Cover
