AKK KC03 2.8MM 120 Degree 800TVL NTSC Switchable Camera with 600mW FPV Transmitter
AKK KC03 2.8MM 120 Degree 800TVL NTSC Switchable Camera with 600mW FPV Transmitter
Description
Specifications of Camera: Scanning System: NTSC Image Sensor: 1/3’’ CMOS Pixels: 1280(H) x 720(V) Synchronization : internal Minimum Illumination: 0.05LUX/F1.2 Horizontal Resolution: 800TVL White Balance: automatic Automatic gain: Auto Back Light Compensation: Auto Digital noise reduction: YES(2D) Gamma Correction: 0.45 Electronic Shutte: PAL: 1/50~1/100000S ; NTSC: 1/60~1/100000S S/N Ratio: more than or equal to 50dB Video output: 1.0Vp-p/75Ω Power Supply: DC5V 1000mA Working current: 135+/-5mA Working Temperature: -40℃ ~ +150 ℃ Specification of Transmitter: Video Format: NTSC/PAL Output Impedance: 50 Ohm Transmitting distance > 3000m (open area) Antenna connector: RP-SMA connector Supply current: 280 mA Operating Temperature: -10 +85℃ Video Band Width: 0-8.0 MHz Audio carrier Frequency: 6.5 MHz Video Input Level: 0.8,1.0,1.2 Vp-p Video Input Impedance: 75 Ohm Audio Input Level: 0.5 ,2.0 Vp-p Audio Input Impedance: 10K Ohm
Notes
Unknown if missing parts
Item Details
Pickup Location
470 Mirror Ct Suite 101
Henderson, NV, 89011
Quality
Auction closes
August 29, 2025 at 2:05 AM
brand
AKKEstimated Retail Price
$33.99
Buyers Premium
15%
Inventory Number
1046111771
Found in
Features
- 800TVL Horizontal Resolution and Minimum Illumination
- 5.8GHz FPV transmitter has double push buttons for easy changing CH and FR
- VTX 5V Out for Cam, Operating Voltage: 7-20 V Output Voltage(VOUT): 5 V,use 2S-4S battery,can not 6S battery
- Low power consumption and micro size make it compatible with all kind of drones and quadcopters.
- Special connecting cable for camera and FPV transmitter, a RTF fpv system for beginners.
