ABS Brake Booster Pump Assembly Compatible With Toyota Highlander Hybrid 2008-2020 Lexus RX350 RX450h#47070-48010 47070-48020

Features

• INTERCHANGEABLE PART NUMBER: 47070-48020 47070-48010, If you do not know how to install it, please ask a professional to install it. The wrong installation sequence will cause the product to fail and shorten its service life
• COMPATIBLE VEHICLES: Power Brake Booster Compatible With 2008 -2020 Toyota Highlander Hybrid Compatible With 2008-2011 Toyota Land Cruiser Compatible With 2010-2020 Lexus RX350 RX450h RX450hL
• NOTICE:The oil inlet pipe and the oil outlet pipe must NOT be inserted at the same time.Please insert the oil inlet pipe first, start the motor intermittently a few times, and then insert the oil outlet pipe when the oil outlet is full
• INSTALLATION INSTRUCTIONS: (1)Before installation, please carefully check whether the model, specification, performance parameters and applicable models of the product meet the requirements of your system.(2)Before installation, clean the oil storage tank and pipeline system to ensure that the pipeline is unblocked. If the brake fluid has been used for a long time and has impurities, please replace it before installation
• INSTALLATION INSTRUCTIONS: (3)Check connection ports of ABS pump are not blocked by dirt. (4)Pay attention to distinguish the fluid inlet and outlet of the product. The pipeline connecting the fluid inlet and outlet shall not be too thin, too long or too many elbows, which will cause too much resistance to make the fluid suction or discharge impeded, resulting in insufficient pressure, flow or noise
• INSTALLATION INSTRUCTIONS: (5)The wire ends shall be connected in the correct direction and fastened to prevent poor contact;(6)If it is necessary to install the accumulator, please install the matching sealing ring at the connection port of the accumulator, otherwise it will produce leakage or air intake and generate noise
• ENVIRONMENT REQUIREMENTS FOR PRODUCT: (1)The temperature used for ABS brake pump shall meet -40 ℃ ~ +120 ℃, and the instantaneous temperature is allowed to reach 150 ℃. (2)It is recommended to use special brake fluid dot4# (Note: it is not allowed to mix with other different types of fluid). (3)The using contents should be free of sediment or other impurities and mixed fluid; replace it after used 2 years or drove 20K KM
• CLEANLINESS REQUIREMENTS: the fluid shall be clean and free from water, sediment, metal chips, cotton yarn head and other dirt particles The filtering accuracy is 25um The fluid level of the new car shall be regularly checked and the brake fluid shall be replaced every 5000km of the daily car. The brake system shall be cleaned and checked for leakage. The oil tank, oil filter and pipeline shall be cleaned to discharge dirt and dirty oil
