60A Solar Charge Controller MPPT 12V 24V 36V 48V Controller 60amp Solar Charge Regulator MPPT 160V w/LCD Display Work with AGM, Gel, Flooded and Lithium
60A Solar Charge Controller MPPT 12V 24V 36V 48V Controller 60amp Solar Charge Regulator MPPT 160V w/LCD Display Work with AGM, Gel, Flooded and Lithium
Description
MPPT Solar Charge Controller 60A , 12V/24V/36V/48V Auto Work 60A mppt solar charge controller is new upgrade version，Better funcations and advanced technology . Added Features: ★Blacklight LCD Display ★The display directly shows the amount of charge: KWH, without the need for other measuring instruments ★Two new vents are added for scientifically designed convection cooling. ★More Safety Protection ★Maximum DC/DC transfer efficiency is as high as 99% MPPT 60A Technical datas : Rated charge current:60A 12V battery system:open circuit voltage ≤72V(Voc) maximum. PV input power:720W 24V battery system:Open circuit voltage ≤108V(Voc) maximum.PV input power:1440W 36V battery system:Open circuit voltage ≤144V(Voc) maximum.PV input power:2100W 48V battery system:Open circuit voltage ≤160V(Voc) maximum.PV input power:2800W System nominal voltage :12V/24V/36V/48V DC Auto identifying Battery voltage range: 9V~55V Max.PV open circuit voltage:160VDC Power terminal:6-12 AWG Dimension: 11*6*2.5（in） Weight : 4(ib) Protection function: PV Over Current/power PV Short Circuit PV Reverse Polarity Night Reverse Charging Battery Reverse Polarity Battery Over Voltage Battery Over Discharge Battery Overheating,Controller Overheating Lithium Battery Low Temperature Load Short Circuit Load Overload TVS High Voltage Transients Package List: 1 x 60A MPPT Solar Charge Controller 1 x User Manual (English)
Item Details
Pickup Location
4031 Market Center Dr Suite 303
North Las Vegas, NV, 89030
Quality
Auction closes
July 22, 2025 at 3:53 AM
brand
OOYCYOOEstimated Retail Price
$99.99
color
whiteBuyers Premium
15%
Inventory Number
1048015113
Found in
Features
- 【60A MPPT CHARGING CONTROLLER】 :4-stage battery charging algorithm for a rapid, efficient , safe charging(Bulk Charge, Boost Charge, Float Charge,and Equalization), 60amp Rate Charging current
- 【Wide Range Voltage/Powe Support】60a solar controller supports High PV Input Power/Voltage. The charger controller can accept Solar voltage up to 160V. When battery is 12V system: Suggest Solar power 720W, suggest range: DC20V~DC80V; 1440W 37~105V when in 24V; 2100W 50~160 when in 36V; 2800W 72-160v when in 48V
- 【12V/24V/36V/48V BATTERY SUPPORT】:Negative grounding design controller more safe, controller Compatible with a variety of batteries (lead-acid, lithium, Sealed, Gel, Flooded and LI (LFP) battery charging parameter pre-set, User-defined, etc.)
- 【99% Tracking Technology】MPPT Charge Controller with advanced Maximum Power Point Tracking technology can continuously track the array’s maximum power point to get the maximum power to charge the battery. The tracking efficiency is not less than 98.1% and the peak conversion efficiency is up to 98%
- 【Dual Cooling, Efficient Heat Dissipation】The 60-amp charge controller is constructed with die-cast aluminum, ensuring excellent heat dissipation and reduced power consumption. Additionally,Built-in cooling fan, Fan will ON when temperature >45℃ and off < 40℃,Porous heat dissipation and fan use BEARING technologies increase life UP TO 5000hrs in normal use.
