58 Nut and Bolt Thread Checker Standard and Metric,Bolt Size and Thread Gauge with 23 Standard & 23 Metric Bolt & 12 Drill Bit Gauge,Bolt and Nut Identifier Gauge

Features

• 58 Bolt and Nut Identifier Gauge:The 58 nut and bolt thread checker standard and metric quickly identifies 46 different sizes bolt and nut, bolt sizes and thread gauges including 23 metric sizes (M3 x 0.5 to M24 x 2.0 ), 23 standard sizes (4-40 Coarse to 1-12 Fine), 12 drill bit gauges and imperial and centimetre rulers, 0.5cm Thickened aluminium alloy plate makes it more sturdy and durable
• 23 Metric Thread Sizes:3mm*0.5,3.5mm*0.6,4mm*0.7,4.5mm*0.75,5mm*0.8,6mm*1.0 ,7mm*1.0 ,8mm*1.0 ,8mm*1.25 ,10mm*1.0,10mm*1.25,10mm*1.5,12mm*1.0 ,12mm*1.25 ,12mm*1.5,12mm*1.75,14mm*1.5,14mm*2.0,16mm*1.5 ,16mm*2.0,20mm*1.5 ,20mm*2.5 ,24mm*2.0
• 23 Standard Thread Sizes:4-40 Coarse,6-32 Coarse,8-32 Coarse,10-24 Coarse,10-32 Fine,1/4-20 Coarse,1/4-28 Fine,5/16-18 Coarse ,5/16-24 Fine ,3/8-16 Coarse ,3/8-24 Fine ,7/16-14 Coarse,7/16-20 Fine ,1/2-13 Coarse ,1/2-20 Fine ,9/16-12 Coarse ,9/16-18 Fine ,5/8-11 Coarse,5/8-18 Fine ,3/4-10 Coarse ,3/4-16 Fine ,7/8-9 Coarse ,1-12 Fine
• 12 Sizes Drill Bit Gauges:Φ4,Φ6,Φ8,Φ10,Φ12,Φ14,3/16,1/4,5/16,3/8,7/16,1/2
• Easy to use and carry:The thread gauge has double holes on the top of the thread gauge,which makes it easy to hang on the wall and saves you a lot of space.Thread checker standard and metric are dimensionally accurate and help you quickly identify threads, nuts, screws and drills,equiring just 2-3 seconds to confirm the type of bolt or nut,saving you a lot of time
• Excellent Quality-Durability:The bolt size and thread gauge is made of aluminum alloy 6061.nut and bolt thread checker Standard and Metric surface is anodized to prevent rust and corrosion
• Laser Etching-Readable and Accurate:All of the dimensional markings on the nut and bolt thread checker are laser-etched making the numbers very accurate and easy to read,and bolt size and thread gauge won't come off even after repeated heavy use
• PATENT PENDING:We have filed a patent application for this product
