4Pcs DC 12V Micro Push Pull Solenoid Electromagnet Mini Solenoid Linear Actuator Magnet Valve 4mm Stroke Open Frame Solenoid Electromagnet Linear Motion 5.5W 0.15N

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• Product Name : 12V Micro DC Solenoid Electromagnet; Material : Metal, Electric Magnets Electronic Parts; Note: The product wire color is random, does not distinguish between positive and negative poles.
• Rated Voltage : DC 12V; Power: approx.5.5W; Push Pull Type; Load current 460mA; Coil Resistance: approx. 26ohm; Initial Thrust (pull): 0.15N~0.2N;
• NOTE : Because of its small size and large working current, it generates a lot of heat and is not suitable for long-term power-on. It is recommended that the power-on time does not exceed 1 minute. Generally suitable for instant power-on use.
• Stroke : 4mm/0.157inch; Body Size : 1.02x0.39x0.31inch (Including prominent parts); Head Shaft Length: 0.35inch(The length of the thick head is 0.137inch); Head shaft diameter: 0.196inch(Head hole diameter: 0.07inch); Tail shaft diameter: 0.12inch; Cable Length : 230mm / 9.0inch (No distinction +/-); Body fixed hole diameter: M2 x4;
• Package Content : 4 x Push Pull Type DC Solenoid Electromagnet; Per piece weight : 0.26oz;
