2-Pack, 30Amp (3-PIN) Metri-Pack Waterproof Connector Terminals and Seals 10-12 AWG

Metri-Pack 280 Series Highlight: 30 Amps continuous maximum current rating Low energy, low voltage capability Excellent resistance to temperature, chemicals and abrasion Standard ISO 2.8mm configuration -40ºC to 125ºC temperature range Features & Benefits Metri-Pack 280 Series Sealed System Rated for up to 16V and 46 amps In-line connector are ideally suited for space-limited application Secondary lock and TPA capabilities for improved and more robust system design. Seal retention and protection features help prevent loss or damage to the connector seal. Low engage force improves reliability and ergonomics. Pass SAE J2030* Heavy-Duty Electrical Connector Standard (with silver interface platings) . Mates to ISO, SAE blades for compatibility with existing systems and increased efficiency Min. Cable Diameter 0.137 inch - 3.49mm Max. Cable Diameter 0.20 inch - 5.25mm Gauge Wire: 10 12 AWG The temperature range from -40°C to 125°C,
