2.7inch E-Ink Display HAT,264x176 Pixel Black,White Two-Color 3.3V/5V E-Paper Screen LCD for Raspberry Pi 4B/3B+/3B/2B/Zero/Zero W/Zero WH and Jetson Nano SPI Interface Support Full Refresh

264x176, 2.7inch E-Ink display HAT for Raspberry Pi, SPI interface Overview This is an E-Ink display HAT for Raspberry Pi, 2.7inch, 264x176 resolution, with embedded controller, communicating via SPI interface. Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf label, industrial instrument, and so on. Specifications Operating voltage: 3.3V/5V Interface: 3-wire SPI, 4-wire SPI Outline dimension: 85mm × 56mm Display size: 57.288mm × 38.192mm Dot pitch: 0.217 × 0.217 Resolution: 264 × 176 Display color: black, white Grey level: 2 Full refresh time: 6s Refresh power: 24mW(typ.) Standby power:＜ 0.017mW Viewing angle: ＞170° Package Content 2.7inch e-Paper HAT x1 RPi screws pack (2pcs) x2 PH2.0 20cm 8Pin x1 online development resources and technical support are provided, please contact us via Amazon message FIRST if you need any help.
