1pcs Type-C 18650 Lithium Battery Capacity Tester Module MAh MWh 4 Channel Digital Lithium Battery Power Internal Resistance Detector
1pcs Type-C 18650 Lithium Battery Capacity Tester Module MAh MWh 4 Channel Digital Lithium Battery Power Internal Resistance Detector
Description
Specifications: Operating voltage: 5VDC Applicable battery: meet the stop discharge voltage 2.5 ~ 3.5V, 2.8V starts ~ 4.2V full battery are applicable Power supplying interface: two Type-C interface System language: English / Chinese switchable Test quantity: 4-channel charging and discharging measurement Internal resistance measurement: support, using the direct current two-wire method to test the internal resistance Charging function: support, full automatic cut off charging (does not support charging of lithium iron phosphate batteries) Discharge function: support, automatically stop when conditions are met, discharge current is not adjustable Automatic charging and discharging: support, automatic mode ends when the battery is fully charged Cycle charging and discharging: support, 1~9 cycles adjustable (only automatic mode support) Status prompt: support Heat dissipation mode: fan active heat dissipation Overheat protection: Support Stop discharge voltage: 2.5V, 2.6V, 2.7V, 2.8V, 2.9V, 3.0V, 3.1V, 3.2V, 3.3V, 3.4V, 3.5V, a total of 11 grades adjustable Discharge current: maximum about 1A current, not adjustable, does not support independent transformation Charging voltage: special battery charging chip control, maximum of about 1A charging, full charging voltage 4.2V Power failure save: only save the setting parameters, not save the measurement data Item size: 150 * 103 * 36mm / 5.91 * 4.06 * 1.42in Item weight: 200g / 7.05ounce Package size: 182 * 112 * 50mm / 7.07 * 4.41 * 1.97in Package weight: 260g / 9.17ounce Packing List: 1 * 18650 Battery Capacity Internal Resistance Tester
Item Details
Pickup Location
4031 Market Center Dr Suite 303
North Las Vegas, NV, 89030
Quality
brand
AITIAOEstimated Retail Price
$15.00
color
greenBuyers Premium
15%
Inventory Number
1052089875
Found in
Features
- Measurement parameters: Working voltage: DC5V; Detection voltage: less than or equal to DC5V; Capacity measurement range: 0~99999mAh; Battery internal resistance measurement: support; Measurement error is about 10%; Display real-time voltage/power/current: support; Discharge load: 10W.
- The product supports four-channel capacity and internal resistance measurement, each channel is independent of each other, set up separately and run independently without interfering with each other.
- The compact design of the 18650 battery holder supports flat top batteries and allows for easy measurement (compatible with batteries with discharge voltage between 2.5V and 3.5V, and charging voltage at 4.2V).Please note automatic charging and discharging function is not suitable for lithium iron phosphate batteries.
- This battery tester operates on a DC5V power supply and is equipped with dual Type-C ports (power cord not included, compatible with C-type cables). It utilizes a direct current two-wire method for internal resistance measurement and provides status indicators. It also offers high-temperature protection and active heat dissipation.
- Applications：The 18650 battery capacity tester is specially used to check the capacity, internal resistance, voltage, current, power and other information of the 18650 battery.The integration of charge and discharge saves the tedious operation of disassembling and assembling the battery when replacing the equipment。
