1MHz-6GHz SDR Development Board Open Source Software Radio SDR Development Board Black (Mainboard USB SMA Antenna)

Spec: Item Type: SDR Development Board Material: PCB Basic Parameters: Design Frequency: 1MHz-6000MHz Data Bandwidth: 20MHz Sampling Accuracy ADC DAC: 8bit Sampling Rate ADC DAC: 20Mbps Data And Power Supply Interface: USB2.0 Open Source Level: Fully Open Source (software, hardware) The RF switch determines whether to amplify through a 14dB amplifier The is high pass or low pass filtered by an image suppression filter processing udrffc5072 chip is mixed to 2.6GHz fixed if The latest firmware supports the if variable option If the range is 2.150ghz-2.750ghz input chip mixing to baseband, output differential aliqsignal The chip can limit the bandwidth The chip digitizes the baseband and sends it to cpld and microcontroller for all repair The LPC4320/4330 processor sends the sampled data to the computer via usb Put the RFFC5072 and in the shielding cover to protect them from interference from the outside world and other chips on the board, and try to avoid some chips from electrostatic breakdown Features: Operating frequency from 1MHz to 6GHz Half duplex transceiver Up to 20 million samples per second 8 bit orthogonal sample (8 bit i and 8 bit q) Software configurable RX and TX gain as well as baseband filters Software controlled antenna port power (50 mA at 3.3V) SMA female antenna connector SMA clock female input and output for synchronization Convenient programming button Internal row of pins for expansion High Speed USB 2.0 USB Power Supply Open Source Hardware How to Use: Use according to the selling point diagram instructions. packing list: 1 x Mainboard or 1 x Mainboard 1 x Antenna 1 x Data Cable
